UL20866 Industry Connection Curly Cable PUR Jacket Rated 80C 300V

Product Categories
WCH Cable Industrial Co., Ltd.
Contact Now

UL20866 Industry Connection Curly Cable PUR Jacket Rated 80C 300V

Brand Name : WCH Cable

Model Number : UL20866

Certification : UL, Cul, AWM

Place of Origin : Dongguan, China

MOQ : 200pcs

Price : USD 0.133 per piece

Payment Terms : D/P, T/T, L/C, D/A, Western Union, MoneyGram

Supply Ability : 15,000pcs per week

Delivery Time : 9 days for ready goods

Packaging Details : 200pcs per carton box

Style Number : UL20866

Application : Industry Connection

Rated Voltage : 300V

Conductor : Extremely High Purity Copper

Rated Temperature : 80°C

Insulation : Pure Copper Wire Strands

Standard : UL758, UL1581

Jacket : Polyurethane PUR

Contact Now

UL20866 Industry Connection Curly Cable PUR Jacket Rated 80C 300V

Conductor material: high purity copper wires.

Shield screen: braid or spiral wrap, optional.

Insulation: PVC, PP, HDPE, XLPE, TPE, TPU, etc.

Sheathe: quality polyurethane PUR.

Feature: excellent flex resilience curly cable.

Style Number Conductor Cores Conductor Structure Insulation Thickness Insulation Diameter Jacket Thickness Overall Diameter Conductor Resistance
AWG No/mm mm mm mm mm Ω/KM
UL20866 2C 30 7/0.100 0.25 0.80 0.80 3.30 381
2C 28 7/0.127 0.25 0.90 0.80 3.50 239
2C 26 7/0.160 0.25 1.00 0.80 3.80 150
2C 24 11/0.160 0.25 1.10 0.80 4.10 94.2
2C 22 17/0.160 0.25 1.30 0.80 4.50 59.4
2C 20 21/0.178 0.25 1.50 0.80 4.90 36.7
2C 18 34/0.178 0.25 1.80 0.80 5.50 23.2
3C 30 7/0.100 0.25 0.80 0.80 3.60 381
3C 28 7/0.127 0.25 0.90 0.80 3.90 239
3C 26 7/0.160 0.25 1.00 0.80 4.10 150
3C 24 11/0.160 0.25 1.10 0.80 4.40 94.2
3C 22 17/0.160 0.25 1.30 0.80 4.70 59.4
3C 20 21/0.178 0.25 1.50 0.80 5.20 36.7
3C 18 34/0.178 0.25 1.80 0.80 5.90 23.2
4C 30 7/0.100 0.25 0.80 1.00 3.80 381
4C 28 7/0.127 0.25 0.90 1.00 4.10 239
4C 26 7/0.160 0.25 1.00 1.00 4.30 150
4C 24 11/0.160 0.25 1.10 1.00 4.60 94.2
4C 22 17/0.160 0.25 1.30 1.00 5.00 59.4
4C 20 21/0.178 0.25 1.50 1.00 5.60 36.7
4C 18 34/0.178 0.25 1.80 1.00 6.30 23.2
5C 30 7/0.100 0.25 0.80 1.00 4.10 381
5C 28 7/0.127 0.25 0.90 1.00 4.40 239
5C 26 7/0.160 0.25 1.00 1.00 4.70 150
5C 24 11/0.160 0.25 1.10 1.00 4.90 94.2
5C 22 17/0.160 0.25 1.30 1.00 5.50 59.4
5C 20 21/0.178 0.25 1.50 1.00 6.20 36.7
5C 18 34/0.178 0.25 1.80 1.00 6.90 23.2
6C 30 7/0.100 0.25 0.80 1.00 4.40 381
6C 28 7/0.127 0.25 0.90 1.00 4.80 239
6C 26 7/0.160 0.25 1.00 1.00 5.10 150
6C 24 11/0.160 0.25 1.10 1.00 5.50 94.2
6C 22 17/0.160 0.25 1.30 1.00 5.90 59.4
6C 20 21/0.178 0.25 1.50 1.00 6.50 36.7
6C 18 34/0.178 0.25 1.80 1.00 7.40 23.2

WCH Cable - Professional Manufacturer of XLPE Cable, Curl Cord, Cable Assemblies

UL20866 Industry Connection Curly Cable PUR Jacket Rated 80C 300V

Style Number: UL20866
Rated Grade: 80 deg C, 300 Vac, Horizontal flame.
Conductor: Above 99.99% High purity copper wires
Screen Shield: Optional
Jacket: Extruded Polyurethane PUR
Average thickness: 30 mils (Ref.)
Minimum thickness: 24 mils (Ref.)
Specification: Detailed specification is to be customized per customer's requirement.
Executed Standard: Appliance Wiring Material UL 758.
Application: Internal wiring of electronic equipment and appliances.
Manufacturer: WCH Cable Industrial Co., Ltd.
Manufacture Location: Dongguan, Guangdong, China
Other Name of the Cable: UL Cable, PUR Cable, Control Cable, 300V Cable, UL20866 Cable

UL20866 Industry Connection Curly Cable PUR Jacket Rated 80C 300V
