UL20254 Class 2 Circuits TPU Cable

UL20254 Class 2 Circuits TPU Cable

UL20254 is TPU cable, with 30V low voltage rated, specially for internal and external connection in Class 2 circuits.

• Style Number: UL20254

• Rated Temperature: 60°C

• Rated Voltage: 30V

• Spark Voltage: 3KV.

• Dielectric Strength: 2000Vac for 60 seconds without breakdown.

• Flammability Grade: VW-1, FT1, FT2.

• Conductor Material: High purity copper wire strands, tinned or bare, optional.

• Conductor Size: 36AWG or more.

• Insulation: AWM complying material.

• Insulation Colour: Black, brown, red, orange, yellow, green, blue, voilet, gray, white, pink, transparent, etc.

• Core Quantity: 2 cores or above.

• All individually insulated conductor wires cabled together, twisted lay length to be determined.

• Sheath: High quality Thermoplastic TPU material.

• Sheath Effect: Grossy, Matt, Half matt.

• Screen Shield: tinned copper wire strands, or spiral wrapped with aluminum foil.

• Shield Coverage: 65% minimum.

• Standard: AWM, UL758, UL1581.

• Agile routing and handling.

• High flexibility, suitable to be coiled as curly spiral cable.

• Uniform insulation thickness for easy stripping.

• Resistant to oil, organic solvent, strong acid, gas, and other chemicals.

• Hydrolysis resistant, excellent performance to be mounted with waterproof connector.

• UV resistant.

• Capable of handling temperature extremes to -50°C.

• Application: electronic equipment wiring purpose.

• Case examples: AC Distribution Box, Electric Baker, Hand Mixer, etc.

• No contain of halogens, phthalates, or heavy metals.

• RoHS, and RoHS2 compliant.

• Reach compliant.

• WEEE compliant.

Tag: UL20254, TPU Cable

UL20254 Class 2 Circuits TPU Cable Images
