UL20952 Power Supply UPS TPU Cable

Product Categories
WCH Cable Industrial Co., Ltd.
Contact Now

UL20952 Power Supply UPS TPU Cable

Brand Name : WCH Cable

Model Number : UL20952

Certification : UL, Cul, AWM

Place of Origin : Dongguan, China

MOQ : 3050 meters

Price : USD0.31 per meter

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100,000pcs per week

Delivery Time : 9 days for ready goods

Packaging Details : 610 meters per carton

Conductor Material : Tin-plated copper wire strands

Rated Temperature : 105°C

Insulation : AWM Compliant Materials

Rated Voltage : 600V

Jacket Material : Thermoplastic Polyurethane TPU

Executed Standard : UL758, UL1581, AWM

Application : Power Supply UPS Connection

Contact Now

UL20952 Power Supply UPS TPU Cable

Style Number: UL20952


Rated Temperature: 105 deg C.
Rated Voltage: 600V.
Flammability: UL VW-1 passed.
Uniform insulation thickness for smooth stripping.

Highly flexible, suitable for process of spring curly cord.

Standard: Appliance Wiring Material UL758.
Other approvals: Cul, CSA / Canadian Standards Association.


Application: power supply ups interconnection

Style Number Conductor Quantity Conductor Size Conductor Strands Insulation Thickness Insulation Diameter Jacket Thickness Overall Diameter Conductor Resistance
AWG No/mm mm mm mm mm Ω/KM
UL20952 3C 28 7/0.127 0.76 2.00 1.143 7.10 239.00
3C 26 7/0.16 0.76 2.10 1.143 7.31 150.00
3C 24 11/0.16 0.76 2.20 1.143 7.53 94.20
3C 22 17/0.16 0.76 2.40 1.143 7.96 59.40
3C 20 21/0.178 0.76 2.50 1.143 8.17 36.70
3C 18 34/0.178 0.76 2.80 1.143 8.82 23.20
3C 16 26/0.254 0.76 3.10 1.143 9.47 14.60
4C 28 7/0.127 0.76 2.00 1.143 7.61 239.00
4C 26 7/0.16 0.76 2.10 1.143 7.86 150.00
4C 24 11/0.16 0.76 2.20 1.143 8.10 94.20
4C 22 17/0.16 0.76 2.40 1.143 8.58 59.40
4C 20 21/0.178 0.76 2.50 1.143 8.82 36.70
4C 18 34/0.178 0.76 2.80 1.143 9.55 23.20
4C 16 26/0.254 0.76 3.10 1.143 10.27 14.60
5C 28 7/0.127 0.76 2.00 1.143 8.19 239.00
5C 26 7/0.16 0.76 2.10 1.143 8.46 150.00
5C 24 11/0.16 0.76 2.20 1.143 8.73 94.20
5C 22 17/0.16 0.76 2.40 1.143 9.27 59.40
5C 20 21/0.178 0.76 2.50 1.143 9.54 36.70
5C 18 34/0.178 0.76 2.80 1.143 10.35 23.20
5C 16 26/0.254 0.76 3.10 1.143 11.16 14.60
6C 28 7/0.127 0.76 2.00 1.143 8.79 239.00
6C 26 7/0.16 0.76 2.10 1.143 9.09 150.00
6C 24 11/0.16 0.76 2.20 1.143 9.39 94.20
6C 22 17/0.16 0.76 2.40 1.143 9.99 59.40
6C 20 21/0.178 0.76 2.50 1.143 10.29 36.70
6C 18 34/0.178 0.76 2.80 1.143 11.19 23.20
6C 16 26/0.254 0.76 3.10 1.143 12.09 14.60
7C 28 7/0.127 0.76 2.00 1.143 8.90 239.00
7C 26 7/0.16 0.76 2.10 1.143 9.20 150.00
7C 24 11/0.16 0.76 2.20 1.143 9.51 94.20
7C 22 17/0.16 0.76 2.40 1.143 10.12 59.40
7C 20 21/0.178 0.76 2.50 1.143 10.43 36.70
7C 18 34/0.178 0.76 2.80 1.143 11.34 23.20
7C 16 26/0.254 0.76 3.10 1.143 12.26 14.60
8C 28 7/0.127 0.76 2.00 1.143 9.32 239.00
8C 26 7/0.16 0.76 2.10 1.143 9.65 150.00
8C 24 11/0.16 0.76 2.20 1.143 9.97 94.20
8C 22 17/0.16 0.76 2.40 1.143 10.63 59.40
8C 20 21/0.178 0.76 2.50 1.143 10.95 36.70
8C 18 34/0.178 0.76 2.80 1.143 11.93 23.20
9C 28 7/0.127 0.76 2.00 1.143 9.72 239.00
9C 26 7/0.16 0.76 2.10 1.143 10.06 150.00
9C 24 11/0.16 0.76 2.20 1.143 10.41 94.20
9C 22 17/0.16 0.76 2.40 1.143 11.10 59.40
9C 20 21/0.178 0.76 2.50 1.143 11.45 36.70

UL20952 Power Supply UPS TPU Cable
